Cove Dishwasher Lower Spray Arm Replacement


  • Cove Dishwasher lower spray arm removal
  • Part number 827475
  • How to remove the lower spray arm
  • How to take out the bottom spray arm


The lower spray arm of the Cove Dishwasher can be removed for cleaning.

To remove the lower spray arm:

  1. Remove the bottom rack.
  2. Rotate the lower spray arm coupler counterclockwise.
  3. Lift the lower spray arm and coupler off the sump post and out of the unit.

To install the lower spray arm:

  1. Install the lower spray arm and coupler onto the sump post.
  2. Rotate the coupler until the lower spray arm drops onto the post.
  3. Rotate the coupler clockwise to lock in the lower spray arm.
  4. Install the bottom rack.

Refer to the product Use and Care Guide for further information.
